Keystone Solarix CAT5E UTP RJ45 quick tool SXKJ-5E-UTP-BK-NA
|
Order code: 25286703 Brand: Solarix Guarantee period: 5 years Unit of measurement (UoM): piece Min. purchase amount (UoM): 1 Delivery date: immediately Recommended price excluding VAT: 2,14 EUR | |
|
|
By product
Quick tool unshielded CAT5E RJ45 keystone, black.
Technical Parameters
- Category: CAT5E
- Highest Supported Protocol: 2.5G/5GBASE-T and lower
- Shielded: No
- Min. Port Life: 1000 cycles
- Contact Plating: 50 µ gold
- Termination Module: quick tool
- Conductor Size and Type: AWG 26 - 22, solid
- Housing Material: FR acc. to UL94-0
- Color: Black
- Storage Temperature: -40 °C to 70 °C
- Operational Temperature: -10 °C to 60 °C
- Max. Operational Humidity: 93 %
Product Description
- Quality unshielded category 5E/Class D keystone
- Designed for ethernet protocols, including 2.5GBASE-T and 5GBASE-T*
- Very easy installation with the quick tool pliers SXKJ-NA-BU
- 50 µin gold contact plating
- Dust cover
- The keystone meets the ISO/IEC 11801, EN 50173, and ANSI/TIA 568.2-D cabling standards
- Its form factor complies with the requirements of the EN 60603-7 specifications (i.e. the keystone is compatible with other manufacturers‘ modular outlets that meet this standard)
- The colour of the keystone is black
