Installation cable Solarix CAT5E FTP LSOHFR B2ca-s1,d1,a1 500m SXKD-5E-FTP-LSOHFR-B2ca

Product Installation cable Solarix CAT5E FTP LSOHFR B2<sub>ca</sub>-s1,d1,a1 500m SXKD-5E-FTP-LSOHFR-B2ca - Solarix - Solid Cable

Order code: 27655153

Brand: Solarix

Guarantee period: 5 years

Unit of measurement (UoM): reel 500m

Min. purchase amount (UoM): 1

Delivery date: immediately

Recommended price excluding VAT: 378,50 EUR

reel500m
Product Installation cable Solarix CAT5E FTP LSOHFR B2<sub>ca</sub>-s1,d1,a1 500m SXKD-5E-FTP-LSOHFR-B2ca - Solarix - Solid Cable
By product
Copper Cabling \ Solid Cable \ Category 5E \ Shielded
High quality shielded category 5E installation cable, LSOHFR sheath with B2ca-s1,d1,a1 reaction to fire class, 500 m reel.
recommend | print
Technical Parameters
  • Category: CAT5E
  • Highest Supported Protocol: 2.5/5GBASE-T and lower
  • Shielded: overall foil
  • Bandwidth: 100 MHz
  • Conductor Type and Size: copper wire 0.50 mm ± 0.005 mm,
  • Insulation and Wire Diameter with Insulation: HDPE 1.0 mm,
  • Reaction to fire; Sheath: B2ca-s1,d1, a1; LSOHFR
  • Colour: orange RAL 2003
  • Nominall Cable Diameter: 6.3 mm,
  • Weight: 46 kg/km
  • NVP: 68 %
  • Propagation Delay: 535 ns/100 m
  • Delay Skew: ≤45 ns/100 m
  • Storage Temperature: -20 °C to 60 °C
  • Operational Temperature: -20 °C to 60 °C
  • Installation Temperature: 0 °C to 50 °C
  • Packaging: 500 m/reel,
  • Packaging Size (diameter x height): 380 mm x 320 mm
  • Number of Items on a Pallet: 36 reels (large pallet), 27 reels (small pallet)
Product Description
The Solarix installation cable with the designation SXKD-5E-FTP-LSOHFR-B2ca is a reliable Category 5E shielded cable designed for Ethernet protocols, including 2.5GBASE-T and 5GBASE-T*. The cable construction is F/UTP, LSOHFR jacket type with B2ca-s1,d1,a1 reaction to fire class. The cable conductors are made of high-quality copper wire with 99.97% copper purity. The cable easily meets the requirements of international standards ISO/IEC 11801, EN 50173, and ANSI/TIA 568.2-D. In accordance with CPR (EU Regulation No. 305/2011), the cable has been tested by the independent laboratory FORCE CERTIFICATION in the AVCP 1+ property assessment system and also complies with Decree No. 23/2008 and Decree No. 268/2011 on the technical conditions for fire protection of buildings and is suitable for uses corresponding to cables with this fire reaction class, which are defined in Annex No. 2 to these decrees. Like other Solarix cables, the SXKD-5E-FTP-LSOHFR-B2ca cable is marked in 1 m increments from 0 to 500 m. The cable is supplied on a high-strength wooden reel, which contains all the necessary product information, including barcodes, production batch, description, and the most important technical parameters.
