MICRO blow-in Solarix 72f 9/125 HDPE Fca Black SXKO-MICRO-72-OS-HDPE
Brand:
Solarix
Warranty period:
5 years
Order code:
70299729
Unit of measurement (UoM):
meter
Minimum order quantity (MOQ):
1
MICRO air blow-in fibre optic cable with HDPE jacket and reaction to fire Fca 72 fibres SM 9/125 G.657.A1.
2,09 EUR excluding VAT
Info about product:
+420 533 338 834
Solarix MICRO air blow-in fibre optic cables SXKO-MICRO-OS-HDPE reaction to fire Fca are suitable for blowing into micro tubes and HDPE tubes thanks to the high viscosity HDPE jacket that allows the cable to slide easily along the inner side of the tube. The fibres themselves are stored in a gel-filled tube to protect them from moisture. There are 12 fibres stored in each tube in the 12–96f version and 24 fibres in the 144f version. The primary fibre protection used has a standard diameter of 250 μm, and reduced protection of 200 μm for 144f cable. The fibre optic cable has no metallic elements and is fully dielectric. The fibre itself is of the G.657.A1 OS2 type.
- Type of Cable: [?] blow-in
- Type of Fibre: [?] 9/125 µm
- Reaction to fire CPR: [?] Fca HDPE
- Type of Cable According to the Type of Secondary Coating: gel-filled
- Type of Cable According to the Number of Tubes: MLT
- Operating Temperature: -30 °C to +70 °C
- Installation Temperature: -15 °C to +50 °C
- Storage Temperature: -40 °C to +70 °C
- Fiber specification: G.657.A1 OS2
- Attenuation at 1310nm: 0.32 - 0.36 dB/km
- Attenuation at 1550nm: 0.19 - 0.24 dB/km
- Cable diameter: 5.7 mm
- Cable weight (kg/km): 26 kg/km
- Short-term tensile strength: 930 N
- Short-term pressure resistance: 700 N/10 cm
- Minimum bend radius (short-term): 20x D cable
- Minimum bend radius (long-term): 10x D cable
Datasheets
- EN Datasheet Solarix MICRO cables (381.15 KB, pdf)
- CZ, EN, PL, SK DoP F417-SXKO-MICRO-72-OS-HDPE-Fca-01 (244.56 KB, pdf)
- CZ, EN, PL, SK Solarix DoC - fiber optics (240.29 KB, pdf)
- CZ, EN, PL, SK Solarix REACH - fiber optics (189.48 KB, pdf)
- CZ, EN, PL, SK Solarix RoHS - fiber optics (238.9 KB, pdf)
- EN maintenance and use of Solarix cabling (147.49 KB, pdf)
- EN significant installations of Solarix cabling (2.16 MB, pdf)
- EN profile structured cabling Solarix (4.08 MB, pdf)
