Outdoor cable ADSS 4KN Solarix 48f 9/125 HDPE Fca black SXKO-ADSS-4KN-48-OS-HDPE
Brand:
Solarix
Warranty period:
5 years
Order code:
70282489
Unit of measurement (UoM):
meter
Minimum order quantity (UoM):
1
Self-supporting outdoor ADSS cable, MLT construction, with HDPE jacket and Fca reaction to fire class 48 SM 9/125 fibers.
3,55 EUR excluding VAT
Info about product:
+420 533 338 834
The Solarix SXKO-ADSS-4KN-48-OS-HDPE outdoor optical cable, with Fca reaction to fire class is suitable for outdoor installations thanks to its UV-stable HDPE jacket. The cable is self-supporting with a tensile strength of 4500 N and can be suspended without additional support elements. The fibers themselves are housed in a central gel-filled tube, which protects them from water ingress. They are arranged in groups of 12 fibers per tube. The optical cable contains no metallic components and is fully dielectric. The fiber itself is of the G.657.A1 type.
- Type of Cable: [?] self-supporting,
- Type of Fibre: [?] 9/125 µm
- Reaction to fire CPR: [?] Fca HDPE
- Type of Cable According to the Type of Secondary Coating: gel-filled
- Type of Cable According to the Number of Tubes: MLT
- Operating Temperature: -45 °C to +70 °C
- Installation Temperature: -15 °C to +50 °C
- Storage Temperature: -45 °C to +70 °C
- Fiber specification: G.657.A1
- Attenuation at 1310nm: 0.38 dB/km
- Attenuation at 1550nm: 0.22 dB/km
- Cable diameter: 10, 4 mm
- Cable weight (kg/km): 81 kg/km
- Short-term tensile strength: 4500 N
- Short-term pressure resistance: 2500 N/100 mm
- Minimum bend radius (short-term): 15x D cable
- Minimum bend radius (long-term): 20x D cable
Datasheets
- EN Datasheet Solarix ADSS optic cable (467.23 KB, pdf)
- CZ, EN, PL, SK DoP F507-SXKO-ADSS-MLT-48-OS-HDPE-Fca-01 (200.05 KB, pdf)
- CZ, EN, PL, SK Solarix DoC - fiber optics (203.02 KB, pdf)
- CZ, EN, PL, SK Solarix REACH - fiber optics (189.48 KB, pdf)
- CZ, EN, PL, SK Solarix RoHS - fiber optics (206.58 KB, pdf)
- EN Maintenance and use of Solarix cabling (147.49 KB, pdf)
- EN Significant Solarix cabling installations (2.16 MB, pdf)
